Stainless Steel Union - 1/16" ID , 10-32 Threads, Complete
Part Number #JR-ZU1CS6
VICI Jour stainless-steel unions are for joining two pieces of 1/16" OD tubing, with a choice of four bores for easy connection of solvent lines. Unions are precision machined with a focus on the concentricity of the bore and on surface finish to ensure a completely leak-free connection.
The unions have internal threads, which we recommend for most applications. For high-performance instrumentation applications, internal threads make stronger connections and internal fitting details provide the lowest dead volume.
Two nuts and ferrules ship with each union.
Specifications
For 1/16" OD tubing
Material:
| Materials | |
|---|---|
|
Body |
Type 316 SS |
| Nuts |
Type 303 SS |
|
Ferrules |
Type 316 SS |
Pressure rating:1,375 bar (20,000 psi)
(Varies with tubing material and ID)
For more information on Stainless Steel, refer to Properties of Metals
