1/16" Valco® Stainless Steel Nut (10-32 Thread)
Standard Length
Part Number #ZN1
These nuts are for use with all standard Valco internal fittings and most valves. They also may be used with fittings from other manufacturers. The medium and long types are ideal for metal Valco and Cheminert® valves with more than 8 ports, or where the fitting head may be otherwise inaccessible.
They are sized for use with 1/32", 1/16", and 1/8" OD tubing, and are available in different lengths.
For more information on stainless steel, refer to Properties of Metals
Tech Tip
Using nuts with different lengths will create more space for easier wrench access.
Specs
For 1/32", 1/16", and 1/8" OD tubing
Pressure rating with premium SS tubing and ZF1S6 ferrule:
1,375 bar (20,000 psi)
(Varies with tubing material and ID)
Material: Type 303 Stainless steel
Threads:
Threads | |
---|---|
1/32" | 6-40 |
1/16" | 10-32 |
1/8" | 5/16-24 |
See Also
ValvTool for tightening hex-head fittings
